Tucana 06 Sdl End Milling Machine
Tucana
REQUEST FOR QUOTE
Custom pricing based on specifications
Voltage Reference
Standard 480V/60Hz (US) or 600V/60Hz (Canada) — Please specify during inquiry.
GENERAL FEATURES 1.1 kW 3-phase motor • Quick cutter change spindle Hydro-pneumatic feed enables to adjust the speed of the cutters depending on profile type The cutter stack spindle returns to the st... Read More
Fast Response
Quote within 24 hours
Ships from Michigan
All 50 States & Canada
GENERAL FEATURES
- 1.1 kW 3-phase motor • Quick cutter change spindle
- Hydro-pneumatic feed enables to adjust the speed of the cutters depending on profile type
- The cutter stack spindle returns to the starting point automatically
- Profile stop system is adjustable for 4 different profiles
- PVC (vinyl) and aluminum mullion profiles can be end milled within the range of +45° and -45° angle
- Top guard provides a safer working environment
- Storage for spare tools
- Robust machine body
- Max. diameter of end mill cutter is Ø 180 mm (7″)
- Max. end milling dimensions H=100 mm (4″) x W=225 mm (9″)
STANDART EQUIPMENT
- 1x pneumatic horizontal clamp
- 1x pneumatic vertical clamp
- Air gun
- Profile table
OPTIONAL
- Pneumatic spray mist lubrication system
- Custom fixture for special profiles
- Custom cutter stack
Technical specifications and features are subject to change without prior notice.
